Berøringsfri lågekontakt LMZ

  • 2 sikre PNP-udgange (OSSD)
  • Op til PLe, ved seriekobling
  • Unik kodet
  • IP67/IP69K
  • -25°C - 80°C

Varianter

Favoritter Artikler Pris Kabellængde
spinner symbol
5 m
spinner symbol
0,25 m

Variant

412101

412101
LMZ-U 5M OSSD

spinner symbol

Specifikationer

Activation Distance 12 mm
Conductor size 0,25 mm²
Contact rating max 24Vdc 0.2A
Godkendelser ISO 13849-1, ISO 14119, EN60204-1, EN62061, EN60947-5-1, CE, cULus, TÜV, UL 508
Integrated LED indication Ja
IP-klasse IP67, IP69K
Kabellængde 5 m
Kontakt 2 x OSSD, PNP
Materiale Rustfrit stål 316
Minimum current 1mA
Mounting 2 x M4
Operating temperature -25°C - 80°C
PL e acc. EN ISO13849-1
Recommended mounting gap 5 mm
Safety category 4
SIL 3 acc. IEC62061
